Samson STAGE 266 HT6 User Manual

Guided Tour - SR266
5: DC input - Connect the supplied 12 volt, 200 mA power adapter here, using the strain
relief as shown in the illustration below. WARNING: The substitution of any other kind of
power adapter can cause severe damage to the SR266 and will void your warranty.
6: Output- Use this unbalanced high impedance 1/4" jack when connecting the SR266 to
consumer (-10) audio equipment. Wiring is as follows: tip hot,sleeve ground.
Using the strain relief: Gather up a loop of wire and pass it through the strain relief,
then pass the adapter plug through the loop in order to create a knot.
9

Samson STAGE 266 HT6 Specifications

General

Brand	Samson
Model	STAGE 266 HT6
Category	Microphone system
Language	English
