15
SXD Series Power Amplifiers with DSP
Model SXD3000 SXD5000 SXD7000
Rated Output Power
Stereo both channel driven
8 ohms 300W 500W 700W
4 ohms 450W 750W 1000W
Signal to Noise Ratio (20Hz-20k) 100dB
Distortion (SMPTE-IM) 0.02%
Input sensitivity @8ohms Voltage Gain 5dBu
Voltage Gain 30dB 32dB 34dB
Output Circuitry AB 2-Tier Class H 2-Tier Class H
Current Consumption (115VAC)
@1/8 rated power 4ohms 4.5A 3.8A 5.5A
@1/3 rated power 4ohms 7.2A 10A 9.2A
@ rated power 4ohms, max. 10A 13.6A 16A
Distortion (typical @4 ohms)
20Hz-20kHz,10dB below rated power 0.02% 0.02% 0.02%
IkHz,rated power 1% 1% 1%
Frequency Response @8ohms 1Watt 0/-1dB: 20Hz-20kHz
Damping Factor (400Hz) 120
Input Impedance 20K ohm (balanced)
Input Clipping 10Vrms (22dBu)
Cooling Continuously variable speed fan cooling
Connectors (each channel)
Inputs 3-pin XLR and ¼” TRS, balanced
Outputs Binding post and Speakon®
Controls Power switch, CH A & CH B volume
DSP Controls: UP, DOWN, BACK buttons & EDIT encoder/button
Indicators Signal, -20dB, -10dB, Limit, Thermal
Protection
Short Circuit, Open Circuit, Thermal, RF protection Load protected
against DC faults
DSP
Display 2x16 Character LCD
Modes Manual mode, 2 Full Range, Mono 2-Way, Sub/Sat, 2 Subs
I/O Settings Stereo, Mono A+B Dual, Mono A+B Link, Parallel A Dual, Parallel
A Link
Digital Dynamics function Filter, Crossover, Gain Offset, EQ, Limiter
Digital Delay Function Max 20ms per channel
Digital EQ function per channel f0: 1/12 Octave at 20~20kHz, Gain: +/- 12dB, Q: 0.5~5.0
Presets: DJ, Vocal, Live Sound, Install, Rock, Dance and Jazz
Setup Lock Controls with Code, Factory Reset
Dimensions (LxWxH) 19” x 13” x 3.5” (482mm x 330mm x 88mm)
Net Weight 26.4lbs / 12kg 28.6lbs / 13kg 33lb / 15kg
Specications
