Appendix A (conguration instructions)
System Anl 16.0
BE
BA
AE
RK
SF2
SF1RüF1 SLP/10Vout
VF1RK1 AF1UP1
Default setting
CO1->F02 - 1 (with AF1)
CO1->F03 - 1 (with RüF1)
CO1->F06 - 1 (with SF2)
CO5'->F10
Functionofthe0to10Voutput:
− 1=ControlsignalRK1
− 7=SLPspeed
When
CO1->F21-1
− 9=Differentialtemperature
control
When
CO1->F23-1
− 6=Externaldemand
When
CO1->F18-1
− 5=Outdoortemperature When
CO5->F23-1
Direction 'AA'
