Samson TROVIS 5573 - Page 113

EB 5573 EN 16-31
Appendix A (conguration instructions)
System Anl 16.2
BE
BA
AE
RK
SF2
SF1RüF1
SLP
VF1RK1 UP1 AF1
VF2
UP2
Default setting
CO1->F02 - 1 (with AF1)
CO1->F03 - 1 (with RüF1)
CO1->F06 - 1 (with SF2)
CO5'->F10
Functionofthe0to10Voutput:
− 1=ControlsignalRK1
− 7=SLPspeed
When
CO1->F21-1
− 6=Externaldemand
When
CO1->F18-1
− 5=Outdoortemperature When
CO5->F23-1
Direction 'AA'
