Samson TROVIS 5573 - Page 118

16-36 EB 5573 EN
Appendix A (conguration instructions)
16.2.1.1 Outdoor temperature received or sent as 0 to 10V
signal
Theoutdoortemperaturecanbereceivedatterminals11and12asa0to10Vinputsignal
orissuedasa0to10Voutputsignal.Thezeroofthe0to10Vinputandoutputsignals
can be shifted, if required.
Functions Default Conguration
Outdoor sensor AF1 1 CO1.2->F02-1
Outdoor temperature received or sent as
0to10Vsignal
0
AE
–20°C
+50°C
CO5->F23-1
Direction: AE (receive)
Lowertransmissionrange:–50to+100°C
Uppertransmissionrange:–50to+100°C
AE(terminals11/12)zeroshift 0
5%
CO5'->F07-1
Zero:5to20%
Outdoor temperature received or sent as
0to10Vsignal
0
AE
–20°C
+50°C
CO5->F23-1
Direction: AA for sending
Lowertransmissionrange:–50to+100°C
Uppertransmissionrange:–50to+100°C
AA(terminals11/12)reverse 0
0%
CO5'->F01-0
Zero:0to50%
AA(terminals11/12)PWM 0 CO5'->F10-0
Function:5=Outdoortemperature
