Samson TROVIS 5573 - Page 122

16-40 EB 5573 EN
Appendix A (conguration instructions)
Parameters Default Parameter level: value range
Flow temperature Point 1
Point 2
Point 3
Point 4
70.0°C
55.0°C
40.0°C
25.0°C
PA1,2:–5.0to+150.0°C
Reducedowtemperature Point 1
Point 2
Point 3
Point 4
60.0°C
40.0°C
20.0°C
20.0°C
PA1,2:–5.0to+150.0°C
Returnowtemperature Points 1 to 4 65.0°C PA1,2:5.0to90.0°C
Min.owtemperature 20.0°C PA1,2:–5.0to+150.0°C
Max.owtemperature 70.0°C
1)
PA1,2:5.0to+150.0°C
1)
WithCO1,2->F05-1thefollowing
applies: Max.owtemperature:5.0to50.0°C(50.0°C)
16.2.2 Fixed set point control
Duringthetimes-of-use,theowtemperaturecanbecontrolledaccordingtoaxedset
point.Outsidethetimes-of-use,thecontrollerregulatestoareducedowtemperature.Set
thedesiredratedowtemperatureas'Daysetpoint'andthereducedowtemperatureas
'Night set point'.
Functions Default Conguration
Outdoor sensor AF1 1 CO1.2->F02-0
Parameters Default Switch position: value range
Day set point 50.0°C
:Min.tomax.owtemperature
Night set point 30.0°C
:Min.tomax.owtemperature
Parameters Default Parameter level: value range
Min.owtemperature 20.0°C PA1,2:–5.0to+150.0°C
Max.owtemperature 70.0°C PA1,2:5.0to150.0°C
