16-52 EB 5573 EN
Appendix A (conguration instructions)
Functions Default Conguration
Cooling control 0 CO1,2->F04-1
Four-point characteristic 0 CO1,2->F11-1
Parameters Default Parameter level: value range
Outdoor temperature
Point 1
Point 2
Point 3
Point 4
5.0°C
15.0°C
25.0°C
30.0°C
PA1,2:–50.0to+50.0°C
Flow temperature
Point 1
Point 2
Point 3
Point 4
20.0°C
15.0°C
10.0°C
5.0°C
PA1,2:–5.0to+150.0°C
Reducedowtemperature
Point 1
Point 2
Point 3
Point 4
30.0°C
25.0°C
20.0°C
15.0°C
PA1,2:–5.0to+150.0°C
Basepointforreturnowtemperature:
65.0°C PA1,2:5.0to90.0°C
The limiting factors of the return ow sensor RüF1/RüF2 (CO1, 2->F03) functions apply
during cooling control as well.
Cooling control without outdoor sensor
When the cooling control function is activated in a control circuit without outdoor sensor, only
the adjustment limits for the day and night set points at the rotary switch as well as the 'Base
pointforreturnowtemperature'canbeadjustedinPA1and/orPA2.
Functions Default Conguration
Outdoor sensor AF1 CO1,2->F01-0
Cooling control 0 CO1,2->F04-1
Parameters Default Switch position: value range
Day set point 20.0°C
: –5.0to+150.0°C
Night set point 15.0°C
: –5.0to+150.0°C
Note
