Samson TROVIS 5573 - Page 135

EB 5573 EN 16-53
Appendix A (conguration instructions)
Parameters Default Parameter level: value range
Min.owtemperature 20.0°C PA1,2:–5.0to+150.0°C
Max.owtemperature 70.0°C PA1,2:5.0to150.0°C
Basepointforreturnowtemperature: 65.0°C PA1,2:5.0to90.0°C
− The limiting factors of the return ow sensor RüF1/RüF2 (CO1, 2->F03) functions apply
during cooling control as well.
− The request for a signal by downstream control circuits or externally (when a pre-control
circuit is used) is based on the maximum selection. Therefore, systems (e.g. system Anl3.0)
or systems in which the demand is requested using a 0 to 10V signal are not suitable for
transmitting the signal for required cooling. The 'Set point boost (pre-control circuit)' pa-
rameter can only generate higher and not lower set points in the pre-control circuit.
16.2.14 Differential temperature control
InsystemsAnl1.0and16.0,thedifferentialtemperaturecontrolcausesthedeliveryrateof
pumpUP1tobeadaptedthroughthe0to10Voutputdependingonthedifferencebetween
thesecondaryowtemperatureandthesecondaryreturnowtemperature.Insystem
Anl1.0thesensorinputRüF2isautomaticallyactivatedforthispurposewiththesetting
CO1->F23-1.InsystemAnl16.0,thesensorinputsVF2andRüF2areautomaticallyacti-
vated.TheKP(inuencefactor)determineshowstronglythecontrollerrespondswhenthe
temperature deviates from the set point of the differential temperature control.
Functions Default Conguration
Differential temperature control 0
20.0°C
1.0
20%
CO1->F23-1
Set point of differential temperature control:
0.0to50.0°C
KP(inuencefactor):0.1to10.0
Minimumspeed:0to100%
AA(terminals11/12)reverse 0
0%
CO5'->F01-1
Zero:0to50%
AA(terminals11/12)PWM 0 CO5'->F10-0
(TROVIS5573cannotprocessaPWMsignal)
Function:9=Differentialtemperaturecontrol
Note
