EB 5573 EN 16-59
Appendix A (conguration instructions)
Functions Default Conguration
Storage tank sensor SF1 1 CO4->F01-1
Storage tank sensor SF2 1 CO4->F02-1
Flow sensor VF4 0 CO4->F05
Time-controlled changeover of storage
tank sensors
0 CO4->F19
Discharging protection 0 CO4'->F03-1
Parameters Default Switch position: value range
DHW temperature set point or charging
temperaturewithCO4->F01-0setting
60.0°C
: Min. to max. DHW temperature
DHW temperature sustaining value
40.0°C
: Min. to max. DHW temperature
Parameters Default Parameter level: value range
Min.DHWtemperature1) 40.0°C PA4:5.0to90.0°C
Max. DHW temperature
1)
60.0°C PA4:5.0to90.0°C
Hysteresis
2)
5.0°C PA4:1.0to30.0°C
Charging temperature boost
3)
10.0°C PA4:0.0to50.0°C
Max. charging temperature 80.0°C PA4:20.0to150.0°C(onlywithVF4)
Lag time for storage tank charging pump 1.0 PA4: 0.0 to 10.0
1)
Parameters serve as limitation of the adjustment range for the DHW temperature to be set at the ro-
tary switch
2)
DeactivationvalueT='DHWtemperature'+'Hysteresis'
3)
ChargingtemperatureT='DHWtemperature'+'Chargingtemperatureboost'
16.3.2.1 Cold charging protection
InsystemAnl1.1(-1),thecold charging protection function causes a storage tank charging
tobestartedrstwhentheprimaryowtemperatureissufcientlyhighenough.
TheCO4>F22-1settingautomaticallyactivatestheinputFG2tomeasuretheprimaryow
temperature.Ifthemeasuredprimaryowtemperatureislowerthanthemeasuredstorage
tank temperature (e.g. due to a supply line that has cooled down at the start of a storage
tankcharging),theheatingcircuitvalveismovedtotheadjustedpositionatrst.Thestorage
tankchargingisnotreleasedinabsolutepriorityoperationuntiltheprimaryowtempera-
turehasrisenenoughasaresult.Paralleloperationmustbeadditionallyconguredifitisre-
quired.
