EB 5573 EN 16-73
Appendix A (conguration instructions)
Binary demand processing
Regardless of the operating mode set for control circuit Rk1, except for manual mode, the
controllerregulatestheowtemperaturewheneitherthebinaryinput(terminals03/12)isa
makecontact(BI=0)orabreakcontact(BI=1)incontrolcircuitRk1toatleasttheadjusted
owtemperatureadjustedin'Setpointforbinarydemandprocessing'.
Functions Default Conguration
Demandprocessing,0to10V 0 CO1,2->F16-0
Binary demand processing 0
BI=1
CO1->F17-1
bE=1,bE=0
Parameters Default Parameter level: value range
Set point for binary demand processing 40.0°C PA1:0.0to150.0°C
Demand processing, 0to 10 V
Regardless of the operating mode set for the control circuit concerned (except for manual
mode),thecontrollerregulatestheowtemperatureatleasttothetemperaturecorrespond-
ingwiththe0to10Vsignalconnectedtoterminals11/12.
Functions Default Conguration
Demandprocessing,0to10V 0 CO1,2->F16-1
AEZeroshift 0 CO5'->F07-0
0°C Lowertransmissionrange:0to150°C
120°C Uppertransmissionrange:0to150°C
0 CO5'->F07-1
5% Zero:5to20%
0°C Lowertransmissionrange:0to150°C
120°C Uppertransmissionrange:0to150°C
Binary demand processing 0 CO1->F17-0
Parameters Default Parameter level: value range
Set point boost (primary exchanger control) 5°C PA1,2:0to50°C
