16-74 EB 5573 EN
Appendix A (conguration instructions)
16.4.12 External demand using a 0 to 10V signal
Thecontrollercanrequestademandforthemaximumowsetpoint(withboost,ifneedbe)
byissuingananalog0to10Vsignalforexternaldemand.Forthispurpose,the0to10V
output is used as an alternative to issuing the control signal.
Analog or binary demand processing can be integrated into the analog request for an exter-
nal demand.
Functions Default Conguration
External demand 0
0.0°C
120.0°C
0.0°C
CO1->F18-1
Lowertransmissionrange:0.0to150.0°C
Uppertransmissionrange:0.0to150.0°C
Boost:0.0to30.0°C
AA(terminals11/12)PWM 0 CO5'->F10-0
Function:6=Externaldemand
16.4.13 Creep feed rate limitation with a binary input
It is possible to report to the controller when the creep feed rate has fallen below a certain
levelbyusingalimitswitchoftheprimaryvalveconnectedtotheterminals04/12ortoin-
putRüF1.Eithertheopen(BI=0)orclosedbinaryinput(BI=1)canbeconguredattermi-
nals04/12toindicatethatthecreepfeedratehasfallenbelowacertainlevel.Onlythe
closed binary input at RüF1 can be processed. Shortly after the alert, the controller closes the
valveRk1.Assoonastheowtemperaturefallsbelowthesetpointbymorethan5°Cafter
the valve has been closed, control operation is started again.
Functions Default Conguration
Creep feed rate limitation 0
bin
BI=1
CO5->F12-1
bin(terminals04/12),AnA(RüF1)
When'bin'isselected:BI=0,BI=1
