Appendix A (conguration instructions)
F Function WE Anl
Comments
Function block parameters: value range (default setting)
09 Flash adapta-
tion
0
Not sys-
tems Anl
1.5, 1.6,
3.x, 16.x
CO1->F09-1:onlywhenCO1->F01-1
Function block parameters:
Cycletime:0or1to100min(20min)
KP (gain): 0.0 to 25.0 (0.0)
11 Four-point
characteristic
0
Not Anl
1.5, 1.6
CO1->F11-1:Four-pointcharacteristic(onlywhenCO1->
F08-0)
CO1->F11-0:Gradientcharacteristic
12 Control mode 1
All
1)
CO1->F12-1:Three-stepcontrol
Function block parameters:
KP (gain): 0.1 to 50.0 (2.0)
Tn (reset time): 1 to 999 s (120 s)
TV (derivative-action time): 0 to 999 s (0 s)
TY(valvetransittime):15,…,240s(35s)
CO1->F12-0:On/offcontrol
Function block parameters:
Hysteresis:1.0to30.0°C(5.0°C)
Min. ON time: 0 to 10 min (2 min)
Min. OFF time: 0 to 10 min (2 min)
13 Limitation of set
point deviation
for OPEN sig-
nal
0
All
1)
CO1->F13-1: onlywhenCO1->F12-1
Function block parameters:
Max.systemdeviation:3.0to10.0°C(3.0°C)
14 Release RK1 at
input BI1
0
All
1)
CO1->F14-1:FG1hasnofunction.
Selection:BI=1,BI=0(BI=1)
16 Demand pro-
cessing, 0 to
10V
Input terminals
11/12
0
All
1)
CO1->F16-1:onlywhenCO1->F17-0
Thestandardizedsignaloutput(terminals11/12)isnotavail-
able anymore as a control output.
17 Binary demand
processing
Input terminals
03/12
0
Not for
systems
withSF2/
RF2
CO1->F17-1:onlywhenCO1->F16-0
Selection:BI=1,BI=0(BI=1)
