16-84 EB 5573 EN
Appendix A (conguration instructions)
F Function WE Anl
Comments
Function block parameters: value range (default setting)
07 Optimization 0
All
1)
CO2->F07-1:onlywhenCO2->F01-1and
CO1->F02-1
08 Adaptation 0
All
1)
CO2->F08-1:onlywhenCO2->F01-1,CO1->F02-1
andCO2->F11-0
09 Flash adapta-
tion
0
All
1)
CO2->F09-1:onlywhenCO2->F01-1
Function block parameters:
Cycletime:0or1to100min(20min)
KP (gain): 0.0 to 25.0 (0.0)
11 Four-point
characteristic
0
All
1)
CO2->F11-1:Four-pointcharacteristic(onlywhenCO2->
F08-0)
CO2->F11-0:Gradientcharacteristic
12 Control mode 1
All
1)
CO2->F12-1:Three-stepcontrol
Function block parameters:
KP (gain): 0.1 to 50.0 (2.0)
Tn (reset time): 1 to 999 s (120 s)
TV(derivative-actiontime):0s,donotchangethevalue.
TY(valvetransittime):15,…,240s(35s)
CO2->F12-0:On/offcontrol
Function block parameters:
Hysteresis:1.0to30.0°C(5.0°C)
Min. ON time: 0 to 10 min (2 min)
Min. OFF time: 0 to 10 min (2 min)
13 Limitation of set
point deviation
for OPEN sig-
nal
0
All
1)
CO2->F13-1: onlywhenCO2->F12-1
Function block parameters:
Max.systemdeviation:3.0to10.0°C(3.0°C)
14 Release Rk2 at
input BI2
0
All
1)
WithCO2->F14-1setting:FG2hasnofunction
Selection:BI=1,BI=0(BI=1)
16 Demand pro-
cessing
0to10V
Input terminals
11/12
0
All
1)
CO2->F16-1:DemandprocessinginRk2
Thestandardizedsignaloutput(terminals11/12)isnotavail-
able anymore as a control output.
F Function block number, WE Default setting, Anl System code number
