Samson TROVIS 5573 - Page 171

EB 5573 EN 16-89
Appendix A (conguration instructions)
CO5: System-wide functions (all systems)
IfthecontrollerindicatesCO5->F00-1,anyaccesstothereturnow,owrateandcapac-
ity settings is locked.
F Function WE Anl
Comments
Function block parameters: value range (default setting)
01 Sensor
initialization
1
All
CO5->F01-1,F02-0:Pt1000
CO5->F01-0,F02-0:PTC
CO5->F01-1,F02-1:Ni1000
02
03
04 Summer mode 0
Not sys-
tems Anl
1.5, 1.6,
1.9, 3.5
CO5->F04-1:Activationoftime-dependentsummermode
Function block parameters:
Start date for summer mode: 01.01 to 31.12 (01.06)
No. days until activation: 1 to 3 (2)
End date for summer mode: 01.01 to 31.12 (30.09)
No. days until deactivation: 1 to 3 (1)
Outdoortemperaturelimitforsummermode:0.0to30.0°C
(18.0°C)
05 Delayed
outdoor
temperature
adaptation as
the temperature
falls
0
Not Anl
1.9
CO5->F05-1
Function block parameters:
Delay/h:0.2to6.0°C(3.0°C)
06 Delayed
outdoor
temperature
adaptation as
the temperature
rises
0
Not Anl
1.9
CO5->F06-1
Function block parameters:
Delay/h:0.2to6.0°C(3.0°C)
08 Summer/
standard time
switchover
0
All
09 Frost protection
program II
1
Not sys-
tems Anl
1.5, 1.6,
1.9, 3.5
CO5->F09-0:FrostprotectionprogramI(restrictedfrostpro-
tection)
Function block parameters:
Frostprotectionlimit:–15.0to+3.0°C(3.0°C)
CO5->F09-1:FrostprotectionprogramII
Function block parameters:
Frostprotectionlimit:–15.0to+3.0°C(3.0°C)
0
1.5, 1.6,
1.9, 3.5
