Appendix A (conguration instructions)
F Function WE Anl
Comments
Function block parameters: value range (default setting)
12 Creep feed rate
limitation
0
Not Anl
1.9
CO5->F12-1:Creepfeedratelimitation
Selection:bin(inputterminals04/12),AnA(inputRüF1)
Function block parameters when 'bin' is selected:
BI=1,BI=0(BI=1)
14 Operation UP1 0
3.0, 16.x
CO5->F14-1:feederpumpUP1alsostartstooperatetocov-
er the demand of Rk2.
15 Release
controller at
input BI1
0
All
WithCO5->F15-1setting:FG1hasnofunction
Selection:BI=1,BI=0(BI=1)
16 Returnow
temperature
limitation with
P algorithm
0
All
CO5->F16-1: Returnowtemperaturelimitationonlywithpro-
portional component
19 Temperature
monitoring
0
All
CO5->F19-1:Temperaturemonitoringactive
20 Sensor
calibration
1
All
CO5->F20-1:Setallsensorcalibrationvalues
CO5->F20-0:Deleteallsensorcalibrationvalues
21 Lock manual
level
0
All
CO5->F21-1:Controllerrunsinautomaticmodein switch
position.
22 Lock the rotary
switch
0
All
CO5->F22-1:Rotaryswitchwithoutanyfunction.Itisstill
possible to enter the key number.
23 Outdoor
temperature as
0to10V
signal
0
All
CO5->F23-1:Outdoortemperaturereceived(AE)orsent
(AA)as0to10Vsignal(terminals11/12)
Function block parameters:
Direction: AE, AA (AE)
Lowertransmissionrange:–50.0to+100.0°C(–20.0°C)
Uppertransmissionrange:–50.0to+100.0°C(50.0°C)
F Function block number, WE Default setting, Anl System code number
