EB 5573 EN 16-91
Appendix A (conguration instructions)
CO5': System-wide functions (all systems)
F Function WE Anl
Comments
Function block parameters: value range (default setting)
01 AA reverse
Output termi-
nals11/12
0
All
CO5'->F01-0:0V/0%=ValveCLOSED/pumpOFF
CO5'->F01-1:0V/0%=ValveOPEN/pumpwithmax.de-
livery rate
Function block parameters:
Zero:0to50%(0%)
07 AE zero
Input terminals
11/12
0
All
CO5'->F07-1
Function block parameters:
Zero:5to20%(5%)
Lowertransmissionrange:0to150°C(0°C)
Uppertransmissionrange:0to150°C(120°C)
10 AA PWM
Output termi-
nals11/12
0
All
CO5'->F10-0/-1
(hardwareofTROVIS5573cannotprocessaPWMsignalat
the0to10Voutput)
Function block parameters:
0=0to10Vinput
1=ControlsignalRK1(default)
2=ControlsignalRK2
5=Outdoortemperature
6=Externaldemand
7=SLPspeed
9=Differentialtemperaturecontrol
10=10Vsupply
14=3Vsupply
F Function block number, WE Default setting, Anl System code number
CO6: Modbus (all systems)
F Function WE Anl
Comments
Function block parameters: value range (default setting)
01 Modbus 1
All
CO6->F01-1:Modbusactive
02 16-bit address 0
All
CO6>F02-1:16-bitaddressing(onlywhenCO6>F01-1)
CO6->F02-0:8-bitaddressing
