Appendix A (conguration instructions)
F Function block parameters CO5 Value range
23-1 Direction AE, AA
23-1 Lower transmission range –50to+100°C
23-1 Upper transmission range –50to+100°C
F Function block parameters CO5' Value range
01-1 Zeropoint 0to50%0to50%
07-1 Zeropoint 5to20%
07-1 Lower transmission range 0to150.0°C
07-1 Upper transmission range 0to150.0°C
10-0
/-1
Output
0=0to10Vinput,
1=ControlsignalRK1,
2=ControlsignalRK2,
5=Outdoortemperature,
6=Externaldemand,
7=SLPspeed,
9=Differentialtemperature
control,
10=10Vsupply
14=3Vsupply
Level 6 parameters PA6 Value range
Station address (ST)
1 to 247
1 to 32000
F Function block parameters CO8 Value range
01-1 Error message when BI=0,BI=1,none
10-1 Error message when BI=0,BI=1,none
