EB 5573 EN 16-107
Appendix A (conguration instructions)
F Function block parameters CO4 Value range
14-1 Disinfection set point 60.0to90.0°C
14-1 Set point boost 0.0to50.0°C
14-1 Disinfection temperature sustaining
time
0to255min
21-1 Start speed reduction 5to90°C
21-1 Stop speed reduction 5to90°C
21-1 Min. signal 0to50%0to50%
22-1 Valve position when cold charging
protection is active
1to100%
Level 5 parameters PA5 Value range
Boiler pump ON 20to90°C
Hysteresis 0to30°C
Public holidays
01.01 to 31.12
Vacation periods, Start 01.01 to 31.12
Vacation periods, Stop 01.01 to 31.12
Control circuit assignment 1, 2, 3
Vacation periods, Start 01.01 to 31.12
Vacation periods, Stop 01.01 to 31.12
Control circuit assignment 1, 2, 3
F Function block parameters CO5 Value range
04-1 Start date for summer mode 01.01 to 31.12
04-1 No. days until activation 1 to 3
04-1 End date for summer mode 01.01 to 31.12
04-1 No. days until deactivation 1 to 3
04-1 Outdoor temperature limit 0.0to30.0°C
05-1
06-1
Delay per hour 1.0to6.0°C
09-0
09-1
Frost protection limit –15.0to+3.0°C
12-1 Input bin, AnA
12-1,
bin
Binary input BI=1,BI=0
15-1 Binary input BI=1,BI=0
