Samson TROVIS 5573 - Page 188

16-106 EB 5573 EN
Appendix A (conguration instructions)
DHW circuit
Level 4 parameters PA4 Value range
Min. DHW temperature 5.0to90.0°C
Max. DHW temperature 5.0to90.0°C
Hysteresis 1.0to30.0°C
Charging temperature boost 0.0to50.0°C
Max. charging temperature 20.0to150.0°C
Lag time for storage tank charging pump 0.0 to 10.0
Max.returnowtemperature 0.0to90.0°C
Solar circuit pump ON 1.0to30.0°C
Solar circuit pump OFF 0.0to30.0°C
Max. storage tank temperature 20.0to90.0°C
Control signal DHW for storage tank
charging
5to100%
F Function block parameters CO4 Value range
03-1 KP (limiting factor) 0.1 to 10.0
06-1 Stop parallel pump operation in
the event of a system deviation
0to10min
06-1 Flow temperature limit for parallel
operation
20.0to90.0°C
08-1 Activate priority in the event of a
system deviation
0to10min
08-1 KP(inuencefactor) 0.1 to 10.0
09-1 Activate priority in the event of a
system deviation
0to10min
12-1 KP (gain) 0.1 to 50.0
12-1 Tn (reset time) 1 to 999 s
12-1
TV (derivative-action time)
0s,donotchange
the value.
12-1 TY (valve transit time) 15 to 240 s
12-0 Hysteresis 1.0to30.0°C
12-0 Min. ON time 0to10min
12-0 Min. OFF time 0to10min
13-1 Max. system deviation 3.0to10.0°C
14-1 Day of the week 1-7, 1 to 7
14-1 Start time 00:00h to 23:45h
14-1 Stop time 00:00h to 23:45h
