7-4 EB 5573 EN
Start-up and conguration
6. Select function block [q].
Activated function blocks are marked '- 1'.
Deactivated function blocks are marked '- 0'.
7. Activate editing mode for the function block [Û].
blinks.
8. Activate function block [q].
Reading: F__-1
An activated function block is indicated by a black square below (right) the function
block number at the top of the controller display.
or:
Deactivate function block [q].
Reading: F__-0
9. Conrmsetting[Û].
If the function block is not closed, further function block parameters can be adjusted.
a) Set function block parameter [q].
b)Conrmfunctionblockparameter[Û].
If applicable, the next function block parameter is displayed.
Conrmallparameterstoexittheopenedfunctionblock.
Î To set further function blocks, repeat the steps 6 to 9.
10. Select End [q].
11. Exitcongurationlevel[Û].
Î Tosetfurtherfunctionblocksinothercongurationlevels,repeatsteps4to9.
12. Turn the rotary switch back to normal switch setting
(information level).
All function block settings are saved in a non-volatile memory in the controller.
Note
