EB 5573 EN 7-7
Start-up and conguration
Room sensor RF, heating circuit 1 and 2
Outdoor sensor AF1
Flow sensor VF, heating circuit 1 and 2
Flow sensor VF1, primary heat exchanger circuit
Flow sensor VF2 and VF4, DHW circuit
Solar collector sensor VF3
ReturnowsensorRüF
Storage tank sensor SF1
Storage tank sensor SF2
Storage tank sensor of solar circuit SF2
9. Display measured value [Û].
"°C"blinks.
10. Correct measured value [q].
Read the actual temperature directly from the thermometer at the point of measurement
and enter this value as the reference temperature.
11. Conrmcorrectedmeasuredvalue[Û].
Proceed in the same manner to calibrate further sensors.
12. Select End [q].
13. Turn the rotary switch back to normal switch setting
(information level).
