Samson TROVIS 5573 - Page 89

EB 5573 EN 16-7
Appendix A (conguration instructions)
System Anl 1.5
Default setting
CO1->F03 - 1 (with RüF1)
CO4->F01 - 1 (with SF1)
CO4->F02 - 0 (without SF2)
CO5'->F10
Functionofthe0to10Voutput:
− 1=ControlsignalRK1
− 6=Externaldemand
When
CO1->F18-1
− 7=SLPspeed
When
CO4->F21-1
