Appendix A (conguration instructions)
System Anl 1.6 without pre-control
WW
KW
BE
BA
AE
RK
RK1
SLP
VF1 SF1SF2
ZP
RüF1
Default setting
CO1->F03 - 1 (with RüF1)
CO4->F01 - 1 (with SF1)
CO4->F02 - 1 (with SF2)
CO4->F10 -0(DHWcirculationreturnowinstoragetank)
CO5'->F10
Functionofthe0to10Voutput:
− 1=ControlsignalRK1
− 6=Externaldemand
When
CO1->F18-1
− 7=SLPspeed
When
CO4->F21-1
