23
TXM16 and TXM20 System Set-Ups
This system shows the TXM16 power amp oper
-
ating in MONO/AUX1 mode, with two speakers connected to POWER AMP 2 and two moni
-
tor speakers connected to POWER AMP 1. For inputs, two microphones are connected to channel 1 and 2’s low-imped
-
ance inputs, and the output of the Bass Direct Box is also connected to the Low-Impedance input on channel 4. The Keyboards, as well as the Lead and Rhythm Guitar signal processors’ outputs, are connected to the TXM16’s line inputs.
