Samson UHF Micro 32 User Manual

13
Guided Tour - H32
5: Battery holder - Insert a standard
9-volt alkaline battery here, being sure to
observe the plus and minus polarity
markings shown. We recommend the
Duracell MN 1604 type battery. Although
rechargeable Ni-Cad batteries can be
used, they do not supply adequate current
for more than four hours.
WARNING: Do not insert the battery
backwards; doing so can cause severe
damage to the H32 and will void your
warranty.
Note: As shown in the illustration on the
left, the controls for setting the H32 Group
and Channel indicated below are located
on the opposite side to the battery
compartment:
6: Group selector - Use the supplied
plastic screwdriver to set this to the
desired transmission frequency Group.
7: Channel selector - Use the supplied
plastic screwdriver to set this to the
desired Channel. When two or more
transmitters and receivers are being used
in the same location, they should be set up
to use different Channels within the same
Group. Note that the H32 multifunction
LED (see #2 on the preceding page) blinks
whenever an unavailable Channel within a
Group is selected. See the “Setting Up
and Using the Micro 32 System” section
on page 12 and Appendix B on page 17 in
this manual for more information.
TRANSMITTER MODEL H32
FCC ID: CCRH32M
DOC ID:CAN0000000000
BA999 Z T999N
Technologies Corp.
GR
CH
0
9
8
7
6
5
4
3
2
1
0
9
8
7
6
5
4
3
2
1
6
7

Samson UHF Micro 32 Specifications

General

Brand	Samson
Model	UHF Micro 32
Category	Microphone system
Language	English
