Samson XP 106 - Making Connections

21
XP106 • Portable PA System
Instrument*, Keyboard,
Drum Machine
Microphone, Instrument*,
Line Level Device
LINE OUT
MP3 Player,
Portable Audio
Paired Bluetooth
Device
Stage XPD1
Wireless System
SIGNAL FLOW
SIGNAL FLOW
SIGNAL FLOW
SIGNAL FLOW
SIGNAL FLOW
Making Connections
* An active preamp is needed in order to use acoustic
instruments with the XP106.
