Samson XP308i Service Manual

Exploded View Part List
REF NO. DESCRIPTION PART NO. Q'TY REMARK
44 SAMSON LOGO 501-XP308I-2205 2
45 KNOB NECK 100-XP308I-2649 10
46 WASHER 606-LC58FA-130 4
47 TOOTH WASHER 606-F200-002 1
48 NUT 601-F200-001 1
49 COTTON 509-XP308I-252 2
50 EVA 612-XP308I-322 1
51 EVA 612-XPL200-293 6
52 EVA 612-XP308I-323 3
53 SILICONE SHEET 612-XP308I-324 1
54 POWER SW 403-DJ1-107A 1
55 2P 3.96CON ASS'Y(UL1007#18,RED*2,L=200mm) 404-XPL200-2679 1
56 AC INPUT JACK 420-SX1800-195 1
57 1P CONNECTOR WIRE(L=80MM,UL1015#18) 406-XP308I-1088 1
TO AC INPUT JACK
“GND”
58 I'POD INPUT PCB ASS'Y 704-XPL300-7193 1
59 DC FAN 401-XP308I-076 1
60 OUTPUT PCB ASS'Y 704-XP308I-8289 1
61
WOOFER SPEAKER(WOOFER 8Ω/75W,8")
419-XP308I-065 2
62
3P CONNECTOR WIRE(L=550mm,UL1430#18 TS RED/BLACK)
404-XPL200-2775 2
63
TWEETER SPEAKER(8Ω20W ∮25)
419-XP308I-066 2
64 3P CON ASS'Y(UL1430#18,BULE BLACK,L=550mm) 404-XPL100-2676 2
65 SPEAKER TWO FREQUENCY PCB ASS'Y 704-XP308I-8251 2
66 SPEAKER INPUT PCB ASS'Y 704-XP308I-8347 2
67 MIXER PCB ASS'Y 704-XP308I-8285 1
68 POWER&AMP PCB ASS'Y 704-XP308I-8286 1
69 AC CORD(L-1900 18AWG LP-31 SJT LS-13) 409-XM910-121 1
70 2P CONNECTOR(L=170mm UL1617#18 P=3.96mm) 404-XP308I-3148A 1
TO AC INPUT JACK “N
”
71 FERRITE CORE 415-F806-264 1
72
SAFETY CAPACITOR(2200pF/250VAC,M,Y5U,Y2,TAPING)
413-XP308I-1148 2
S1 SCREW TTB 4*10 602-PTPB4010-665 2
S2 SSCREW(3*8mm TTB) 602-2002-077 8
S3 SCREW TTB3*8 602-XM610-528 24
S4 SCREW M2.6*6 602-XM610-514 5
S5 SCREW M2*5 602-DD2220-301 4
S6 SCREW 2.6*6 602-KMD510-158 4
S7 SCREW 2.6*6 602-ISOB2606-654 9
S8 SCREW M3*6 602-SX1200-544 4
S9 SCREW BM4*8 602-CDVD2001-351 2
S10 SCREW 602-TTB5024-668 22
S11 SCREW TTB 4*16 602-BTTB4016-676 20
S12 SCREW M6*16 602-PISO6016-667 8
9
