Samson XP308i Service Manual

Exploded View Part List
REF NO. DESCRIPTION PART NO. Q'TY REMARK
1 PUSH KNOB 100-L2400-2569 10
2 CONTROL KNOB(B) 100-XM610-2217 21
3 KNOB CAP(WHITE) 100-XM610WHT-2218A 7
4 KNOB CAP(RED) 100-XM610RED-2218A 1
5 KNOB CAP(BLU) 100-XM610BLU-2218A 1
6 KNOB CAP(SLIVE) 100-XM610SIL-2218A 12
7 INLAY 501-STAGE-2167 1
8 PANEL ASS’Y 703-STAGE-1235 1
9 CARD CHASSIS 100-XP300-2517 1
10 TOP DOCK 100-XP300-2503 1
11 IPOD BUTTON 100-XP300-2504 1
12 SUPPORT 200-L1200-589 5
13 LED HOLDER 504-BD1550-067 12
14 AMPLIFIIER CASE ASS’Y 701-XP308I-1243S 1
15 CONTROL KNOB 100-STAGE-2625 2
16 REAR PAD(A) 300-STAGE-1672 2
17 REAR BRACKET 300-STAGE-1674 2
18 SHAFT 200-SP300-583 2
19 WASHER 606-B300-030 2
20 REAR PAD(B) 300-STAGE-1673 2
21 HANDLE 100-STAGE-2623 4
22 HANDLE COVER 100-STAGE-2624 4
23 HANDLE PAD 604-STAGE-496 4
24 SCREW THUMB 601-EX250-038 2
25 REAR CASE ASS’Y 701-STAGE-4438 2
26 FRONT CASE 100-STAGE-2630 2
27 SPRING SHEET 300-XP308I-1706 4
28 SLIDE 100-STAGE-2622 2
29 GRILL 300-STAGE-1675 2
30 REAR COVER 100-STAGE-2628 1
31 INSULATION SHEET 501-SP300-2182 1
32 SHIELE FENCE 300-SP300-1685 1
33 HEATSINK 425-KMD3500-016A 4
34 HEAT SINK ASS’Y 703-SP308-1240 1
35 HEAT SINK 425-STAGE-123 1
36 BOTTOM INLAY 300-SP300-1684 1
37 INSULATION SHEET 501-SP300-2181 1
38 FILP FOOT 603-SP300-377 1
39 HOOK GUIDE 200-STAGE-578 4
40 HOOK 300-SP300-1683 2
41 BOTTON BRASS 200-SP300-582 2
42 CAM GUIDE 200-XP308I-586 4
43 MICA 501-TST4-2028 2
8
