....4 T0568 3301-000314 BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,- 1 S.N.A
....4 T0568 3301-000314 BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,- 1 S.N.A
....4 T0568 3301-000314 BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,- 1 S.N.A
....4 CN400 3711-005470 HEADER-BOARD TO CABLE;BOX,30P,1R,1.25mm, 1 S.A
....4 CN601 3711-005471 HEADER-BOARD TO CABLE;BOX,12P,1R,1.25mm, 1 S.A
....4 T0010 BN27-00009A COIL CHOKE;SMD 12X12X6,EOS,33UH,15%,-,0. 1 S.A
....4 S201 BN32-00005A SENSOR SW-TILT;SPSF100100,DC5V,1mA,-10 ~ 1 S.A
....4 M0018 BN97-00489N ASSY MICOM;DE17PS*,W/W 1 S.A
.....5 IC520 0903-001402 IC-MICROCONTROLLER;NT68F632ALG,8Bit,PLCC 1 S.N.A
....4 R610 2007-000208 R-CHIP;1.1Kohm,1%,1/10W,TP,1608 1 S.A
....4 CN200 3711-005509 HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S 1 S.A
....4 R605 2007-000842 R-CHIP;3Kohm,1%,1/10W,TP,1608 1 S.A
....4 CIS7 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45§-,96.5Sn/ 1.95 S.N.A
....4 IC113 1105-001284 IC-DRAM;636165,-,16Mbit,1Mx16Bit,TSOP,50 1 S.A
....4 IC113 1105-001284 IC-DRAM;636165,-,16Mbit,1Mx16Bit,TSOP,50 1 S.A
....4 IC113 1105-001284 IC-DRAM;636165,-,16Mbit,1Mx16Bit,TSOP,50 1 S.A
....4 T0077 BN41-00586C PCB MAIN;DALI-2,FR-4,4L,MP1.2,1.0T,145*1 1 S.N.A
...3 CIS2 BN60-00011B FASTENER-PEM NUT;DE17PS,FASTENER-PEM/NUT 4 S.N.A
...3 T0245 0202-001522 SOLDER-WIRE FLUX;LFA3-107,-,D1.2,96.5Sn/ 0.01 S.N.A
..2 M0131 BN63-01079A GASKET;,CONDUCTIVE FAB,4MM,10MM,10MM,GRA 1 S.N.A
0.1 BN91-00841Q ASSY LCD-SPZ(DALI2);DE17PS* 1 S.N.A
..2 M0215 BN07-00218A LCD-PANEL;LTM170E8-L21,Dali2,6BIT FRC,35 1 S.A
..2 M0131 BN63-00995A GASKET;GY17MS,CONDUCTIVE FAB,4MM,15MM,10 1 S.N.A
0.1 M0113 BN92-00956A ASSY P/MATERIAL;DI17PS,BASIC 1 S.N.A
..2 T0376 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,-,-- 0.032 S.N.A
..2 M0505 BN96-00838A ASSY MISC P-WALL MOUNTING;DI17PS,TEXTURE 1 S.A
...3 CIS BN61-00934A BRACKET-WALL FRONT;DALI17",SECC,T2.0 1 S.N.A
...3 CIS BN61-00935A BRACKET-WALL REAR;DALI17",SECC,T2.0 1 S.N.A
...3 CIS BN61-01043A BRACKET-WALL MOUNT;DI17PS/DI19PS,SK-5,T0 1 S.N.A
...3 T0059 BN68-00473H MANUAL FLYER-CARD;Dali Wall Mount,SyncMa 1 S.N.A
...3 M0132 BN96-00196A ASSY MISC P-SCREW;MODIGLIANI ,SCREW-WOOD 1 S.A
..2 T0081 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 3 S.N.A
..2 T0524 6902-000642 BAG PE;HD/NITR/HD(DOUBLE),T0.015/T0.5/T0 1 S.N.A
0.1 M0019 BN92-01091K ASSY LABEL;DI19BSASQ/XAX,MEXICO 1 S.N.A
0.1 M0045 BN92-01371P ASSY ACCESSORY;DE17PSQAQ/XAX 1 S.N.A
..2 M0125 BN39-00246F CBF SIGNAL-DVI(D);1703FP,24P/24P,20276-D 1 S.A
..2 M0045 BN96-02129H ASSY ACCESSORY;DE17_19PSQAQ/XAX 1 S.A
...3 T0268 3903-000085 CBF-POWER CORD;DT,US,BP3/YES,I(IEC C13/C 1 S.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2 1 S.N.A
...3 M0114 BN39-00244B CBF SIGNAL;MO15PS,15P/15P,20276-N,1830mm 1 S.A
...3 M0215 BN96-00881K ASSY MANUAL P-IB+QSG;DE17PS,DE19PS,SYNCM 1 S.N.A
....4 QUICKSETUP BH68-00376L MANUAL FLYER-04,QSG;LCDQUICK SETUP GUIDE 1 S.N.A
....4 IB BN59-00395K S/W DRIVER-02,IB;COMM,W/W,SYNCMASTER,W/W 1 S.N.A
...3 ACCESSROY BN68-00797A MANUAL FLYER-02,WARRANT CARD;SAMEX BASIC 1 S.N.A
...3 T0238 BP68-00515A MANUAL FLYER-REGISTRATION CARD;PRC CARD, 1 S.N.A
0.1 M0003 BN92-01389Q ASSY BOX;DE17PSQFV/XAX,SEM,MEXICO,TCO99 1 S.N.A
..2 BOX BN69-01024A BOX-03;S/M173P PLUS(DE17PS),SW4,A,YEL,A1 1.01 S.N.A
..2 M0103 BN66-00007A LEVER-TOP;ALL MODEL,LDPE,WHITE 1 S.N.A
0.1 MP1.4 BN91-00591U ASSY MISC-ADAPTOR;CX718T-QH 1 S.N.A
..2 M0158 BN44-00131A ADAPTOR;SAD04214-UV,Internal,90 ~ 264Vac 1 S.A
6 Electrical Parts List
6-8
Code No.
Loc. No. Description Specification EA SA/SNA
Remarks
To Next Page
