6 Electrical Parts List
6-9
DE17PSQRV/XAX 173P PLUS,DE17P,17,LCD-MO,MEXICO
0.1 M0001 BN90-00662E ASSY COVER FRONT;DI17PSQRV/*,AL+BR01,RED 1 S.N.A
..2 T0003 BN96-00778G ASSY COVER P-FRONT;DI17PS,ABS HB,RED 1 S.A
...3 M0081 6003-001522 SCREW-TAPTITE;CH,+,B,M3,L8,ZPC(YEL),SWRC 4 S.N.A
...3 C/F BN61-00809A HOLDER-COVER LOCK;DALI 17,ABS 2 S.N.A
...3 M0112 BN63-01032D COVER-FRONT;DALI 17,AL T1.0 RDN-8410 1 S.A
...3 T0069 BN63-01033E COVER-MIDDLE;DALI 17,ABS HB BR01 1 S.A
...3 C/F BN64-00221A DECORATION-LED;DALI 17,PC CLEAR 1 S.N.A
...3 M0007 BN64-00225A KNOB-FUNCTION;DALI 17,ABS HB 1 S.N.A
...3 C/F BN73-00061B RUBBER-PROTECT;DALI 17,RUBBER,BLK,PANTON 1 S.N.A
...3 M0145 BN96-00848A ASSY BOARD P-FUNCTION;DI17PS,FUNCTION 1 S.A
0.1 M0002 BN90-00666C ASSY COVER REAR;DI17PSQRV/,AL+BR01,RED 1 S.N.A
..2 M0006 BN63-01035E COVER-REAR;DALI 17,ABS HB RD01,RDP-2407, 1 S.A
0.1 M0216 BN90-00706Q ASSY STAND;DE17PSQRV/EDC 1 S.N.A
..2 M0003 BN96-01998D ASSY STAND P;DE17P (S/M 173 PLUS),ABS HB 1 S.A
...3 T0081 6001-000346 SCREW-MACHINE;FH,+,M3,L4,ZPC(YEL),SWRCH1 2 S.N.A
...3 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 5 S.N.A
...3 M0081 6003-000276 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(YEL),S 4 S.N.A
...3 M0081 6003-000301 SCREW-TAPTITE;BH,+,S,M4,L6,ZPC(YEL),SWRC 1 S.N.A
...3 M0081 6003-001010 SCREW-TAPTITE;FH,+,B,M3,L6,ZPC(YEL),SWRC 3 S.N.A
...3 M0081 6003-001119 SCREW-TAPTITE;FH,+,-,S,M4,L10,ZPC(BLK),S 4 S.N.A
...3 M0081 6003-001136 SCREW-TAPTITE;BH,+,B,M4,L8,ZPC(YEL),SWRC 4 S.N.A
...3 M0081 6003-001185 SCREW-TAPTITE;FH,+,B,M3,L8,NI PLT,SWRCH1 12 S.N.A
...3 M0081 6003-001238 SCREW-TAPTITE;FH,+,S,M4,L8,ZPC(BLK),SWRC 3 S.N.A
...3 STD 6011-001445 BOLT-SOCKET;4-40 UNC,L7,NI PLT,BRASS,HEX 4 S.N.A
...3 M0326 6501-000113 CABLE TIE;DA-100,T1,W2.5,L102,WHT,NYLON 1 S.N.A
...3 M0134 BN39-00452A CBF-STAND CABLE;DI17PS,UL20276#32,UL,15P 1 S.A
...3 M0142 BN61-00251A FOOT-RUBBER;GH17BS,RUBBER,T1.6 4 S.N.A
...3 STD BN61-00827D STAND-REAR BODY;DI1*PS,ABS HB,RD01,RDP-2 1 S.A
...3 STD BN61-00828D STAND-NECK FRONT;DI1*PS,ABS HB,BR01 1 S.A
...3 STD BN61-00830D STAND-FRONT BODY;DI1*PS,ABS HB,BR01 1 S.A
...3 STD BN61-00841D STAND-REAR DECO;DI1*PS,ABS HB,RD01,RDP-2 1 S.A
...3 STD BN61-00844D STAND-HINGE COVER;DI1*PS,ABS HB,BR01 1 S.A
...3 M0009 BN61-00854D STAND-BOTTOM;DI1*PS,ABS HB,BR01 1 S.A
...3 STD BN61-00855D STAND-JACK COVER;DI1*PS,ABS HB,BR01 1 S.A
...3 STD BN61-00856A STAND-SWIVEL;DALI 17,ABS 1 S.N.A
...3 STD BN61-00857D STAND-SWIVEL COVER;DI1*PS,ABS HB,BR01 1 S.A
...3 STD BN61-00859D STAND-COVER AL;DALI 17,AL,T1.0 RED,RDN-8 1 S.A
...3 STD BN61-00860A STAND-BOTTOM AL;DALI 17,AL 1 S.N.A
...3 STD BN61-00880A STAND-GUIDE AL;DALI 17,ABS 1 S.N.A
...3 M0131 BN63-00951A GASKET;RT15NS,CONDUCTIVE FAB,5,17,60,GRA 1 S.N.A
...3 STD BN63-01036D COVER-REARCAP BOTTOM;DI1*PS,ABS HB,BR01 1 S.A
...3 STD BN63-01056D COVER-REARCAP SUB;DI1*PS,ABS HB,BR01 1 S.A
...3 STD BN63-01161A PROTECTOR-TAPE;DI17PS,T0.4,9*30 6 S.N.A
...3 M0122 BN96-00839A ASSY MISC P-HINGE;DI17PS,ZNCD2 1 S.N.A
...3 T0346 BN96-00882A ASSY MISC P-PIVOT HINGE;DI17PS 1 S.N.A
...3 M0081 6003-000008 SCREW-TAPTITE;BH,+,S,M3,L4,ZPC3,SWRCH18A 1 S.N.A
0.1 M0112 BN91-00752D ASSY SHIELD;DI17PSQRV/*,RED 1 S.N.A
..2 T0081 6001-000346 SCREW-MACHINE;FH,+,M3,L4,ZPC(YEL),SWRCH1 4 S.N.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 8 S.N.A
..2 M0081 6003-001238 SCREW-TAPTITE;FH,+,S,M4,L8,ZPC(BLK),SWRC 4 S.N.A
..2 M0081 6003-001336 SCREW-TAPTITE;CH,+,S,M3,L5.5,ZPC(YEL),SW 4 S.N.A
..2 T0081 BN96-00837A ASSY MISC P-SHIELD PCB;DI17PS,SECC T1.0 1 S.N.A
...3 T0178 BN63-01034A SHIELD-PCB;DALI 17,SECC,T1.0 1 S.N.A
..2 M0173 BN96-00890D ASSY STAND P-CAP;DALI 17_19,ABS HB,RED 1 S.A
Code No.
Loc. No. Description Specification EA SA/SNA
Remarks
6-2 DE17PSQRV/XAX Parts List
To Next Page
