Samsung 320BX - Page 33

33
Preparations
1
1 Preparations
z RS232C cable
Connector: 9-pin D-Sub
Cable: Cross (reversed) cable
z Connection
-P1- -P1- -P2- -P2-
Female Rx
Tx
Gnd
2
3
5
-------->
<--------
---------
3
2
5
Rx
Tx
Gnd
Female
1
5
1
59
6
9
6
RS232C IN
