3. Installing the Product

34 English 8/2020. Rev 0.3

NOTICE

 Connect a ground cable between the SMU and the Rack Frame (SCREW M5 x 10L). (Torque:

5.1–6.1 Nm [50–60 kgf∙cm])

 Verify that the torque setting is correct.

Figure 3-21: Ground Cable Connection to the SMU
