Contents
For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH
visit: samsung.com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/data_corner.html
Safety Information 3
General information 3
Installing the unit 4
Power supply line, fuse or circuit breaker 4
Installation Procedure 5
Step 1 Choosing the installation location 5
Step 2 Fixing the outdoor unit in place 7
Step 3 Connecting the power cables, communication cable, and controllers 8
Step 4 Optional: Extending the power cable 13
Step 5 Connecting the refrigerant pipe 15
Step 6 Optional: Cutting and flaring the pipes 16
Step 7 Connecting up and removing air in the circuit 17
Step 8 Adding refrigerant (R-410A) 18
Step 9 Optional: Installing DPM 20
Step 10 Performing the gas leak test 21
Step 11 Connecting the drain hose to the outdoor unit 21
Step 12
Insulating the refrigerant pipes 22
Step 13 Checking the earthing 23
Step 14 Performing final check and trial operation 23
Extra procedures 27
Pumping down refrigerant 27
Relocating the indoor and outdoor units 27
Using the stop valve 27
Appendix 29
COMMISSION DELEGATED REGULATION (EU) No 626/2011
i)
29
Troubleshooting 53
Technical specifications 55
