PCB Diagram and Parts List
Samsung Electronics 5-5
5-2-2 SUB PCB
QAC018JXADCH
No. Function
1 MODE SELECTOR
2
MAIN PCB connection
(Key, Switch signal)
3
MAIN PCB connection
(Key, 7-segment signal)
4
MAIN PCB connection
(DC 5V,12V)
5DC 12V
6
Solution communication
1
2
3
4 5 6
