PCB Diagram and Parts List
Samsung Electronics 5-9
QAC024*XA*CH, AC030JXADCH, AC036*XA*CH, AC042JXADCH, AC048JXADCH
①
L1:BRN
②
N1:SKY-BLU
③
#1-#3:AC220~240V
L1-AC POWER L phase N1-AC POWER N phase CN01-AC POWER
3 1
2
5-2-6 EMI PCB
