5-2 Samsung Electronics
①
#1:GND
②
#1:DC310V#3:GND
#4:DC15V#5:FANRPM
#6:RPMFEEDBACK
③
#1:FUSECHECKSIGNAL
#2:GND
④
#1:DC12V
#4:REMOCONSIGNAL
#5:GND 
⑤
#1:DC12V
#2:LED0
#3:LED1
#4:LED2
#5:LED3
#6:LED4
#7:LED5
#8:REMOCONOUTPUTSIGNAL
#9:AUTOSWITCH
#10:REMOCONINPUTSIGNAL
#11:GND
#12:DC5V
#13:GND
⑥ ⑦
#1:GND
#2:EXT-CTRLSIGNAL
⑧
#1:EVA-INTHERMISTOR
#2:GND
#3:EVA-OUTTHERMISTOR
#4:GND
#5:DISCHARGETHERMISTOR
#6:GND
⑨
#1:F/SSIGNAL
#2:GND
⑩
#1:D/PPOWER(DC12V)
#2:GND
⑪
#1:DC12V
#2:ERRORSIGNALOUTPUT(GND)
#3:DC12V
#4:COMP/OPER.
SIGNALOUTPUT(GND)
⑫
#1:GND
#3:DC5V
#4:EEPROMSELECT
#5:EEPROMSO
#6:EEPROMSI
#7:EEPROMCLK
⑬
#1:DC12V
#2:COM2PCTRLMICOM
#3:COM2VCHECKA
#4:COM2VCHECKB
#5:COM2MICOMAD
#6:DC5V
#8:COM2C
#9:COM2D
#10:COM2TXD
#11:COM2RXD
#12:GND
⑭
#1:DC12V
#2:VENTILATORSIGNAL
OUTPUT(GND)
⑮
#1:DC12V
#2:HUMANSENSINGSENSOR
COMM(TXD)
#3:HUMANSENSINGSENSOR
COMM(RXD)
#4:GND
⑯
#1:INDOORTHERMISTOR
#2:GND
⑰
#1~#4:EEVSIGNALOUTPUT
#5:DC12V
#6:DC12V 
⑱
#1:DC12V
#2~#5:LOUVERSIGNALOUTPUT
⑲
#1:DC12V
#2~#5:LOUVERSIGNALOUTPUT
#6:DC12V
#7~#10:LOUVERSIGNALOUTPUT
⑳
#1:DC12V
#2~#5:LOUVERSIGNAL
OUTPUT
㉑
#1:GND
#2:GND
#3:SPISIGNALOUTPUT(DC12V)

㉒
#1:POWER(L)
#2:POWER(N)
㉓
#1:COM1(F1)
#2:COM1(F2)
#3:V1(DC12V)
#4:V2(GND)
#5:COM2(F3)
#6:COM2(F4)
CN101-GND
CN301-DOWNLOAD
CN81-ERROR/COMPCHECK
CN412-INDOORTHERMISTOR
(21)CN801-SPI
CN701-BLDCMOTOR
CN83-EXTCTRL
CN201-EEPROM
CN808-EEV
TB101-ACPOWER
CN140-FUSECHECK
CN413:THERMISTOR
CN311-2WIREDREMOCON
CN807-LOUVER5
TE04-COMMUNICATION
CN809-AUTOMATIC
ELEVATINGGRILLE
CN411-FLOATSWITCH
CN804-VENTILATOR
CN806-LOUVER3/4
CN501-DISPLAY
CN103-DRAINPUMP
CN401-HUMANSENSING
SENSOR
CN805-LOUVER1/2
