PCB Diagram and Parts List
5-6 Samsung Electronics
①
L1:BRN
②
N1:SKY-BLU
③
#1-#3:AC220~240V
L1-AC POWER L phase N1-AC POWER N phase CN01-AC POWER
3 1
2
5-2-3 EMI PCB
This Document can not be used without Samsung’s authorization.
