Samsung AE080RXYDEG - Page 109

PCB Diagram
114 Samsung Electronics
No. Local Function Description
1 TB-A MAIN POWER DAPC 3013-2P BLK
2 TB-A1 BOOSTER&IMMERSION HEATER DAPC 3013-2P BLK
3 TB-B EXTERNAL CONTROL BR-1000C2-26P BLK
4 CNP003 MC-COMMON YTR250
5
CNP501
3-WAY VALVE
YW396-05AV WHT
6 CNP401 HEATER THERMOSTAT YW396-03AV WHT
7
CNP002
MC2-A
YTR250
8 CNP001 MC1-A YTR250
9
CNS002
WATER PUMP SIG/GND
BR-7623C-2P BLK
10 CNS001 WATER PUMP SIG/GND SMW250-03 WHT
11 CNS003 FR CONTROL AKZ350 GRN
12 TB-C F1-F2/DC12V-GND/F3-F4 DAPC 2009-6P BLK
13 CNS047 HEATER SENSOR SMW250-02 BLK
14 CN5045 MIXING VALVE SENSOR SMW250-02 BLU
15 CNS044 ROOM SENSOR SMW250-02 WHT
16 CNS202 F1-F2/GND-DC12V SMW200-04 WHT
17 CNS012 DC12V YW396-02V BLU
18 CNS042 WATER TANK SENSOR SMW250-02 YEL
19 CNS304 F3-F4 YW396-02V RED
20 CNS063 EEV SMW250-06 BLU
21 CNS057 FLOW SENSOR SMW250-04 WHT
22 CNS046 PV SIGNAL(SMART GRID) BR-7623C-2P BLK
23 CNS808 DC FAN SMW250-03 YEL
24 CNS081 ERROR/COMP CHECK SMW250-04 RED
25 CNS083 EXTERNAL CONTROL SMW250-02 RED
26 CNS043
HEATER/EVA-OUT/EVA-IN/
WATER-OUT/WATER-IN SENSOR
SMW250-10 WHT
27 CNS051 EXTERNAL CONTROL/SENSOR WB20L-024-132 WHT
28 CNS041 FLOW SWITCH YW396-02V YEL
29 CNS201 SUB_LED SMW200-07 WHT
30 CNS301 DOWNLOAD YDW200-20 BLK
31 CNP101 EARTH YDW236-01 WHT
