General Overview
Samsung Electronics 21
Item Description Code No. Q’ty Remark
Instruction Manual
DB68-08557A 1
AE090RNYD** Model
Installation Manual (Remocon)
DB68-08469A 1
AE090RNYD** Model
Instruction Manual (Remocon)
DB68-08470A 1
AE090RNYD** Model
Zone sensor
DB95-04396A 2
AE200/260RNW*** Model
AE090RNYD** Model
Cable Tie(8) : AE090RNYD** Model
Sen Temp-Mixing Valve
DB32-00213A
1
Sensor holder
DB61-40055A 3
Sensor clip
DB81-00635A 3
Cable-tie
DB65-10088C 6 (8)
Aluminum Tape
DB72-30040A 3
Rubber Tape
DB62-11304A 3
Insulatior
DB62-04785A 3
Assy Connector Wire DB93-13255A 1
Tube Secondary DB96-24724A 1 AE260RNW***Model
Gasket DB63-04197A 1 AE260RNW***Model
Drain Plug Out DB67-20 011A 1 AE200/260RNW***Model
Cap Drain DB63-10355C 2 AE200/260RNW***Model
Pattern sheet DB98-32365A 1
AE090RNYD** Model
service valve DB96 -13833A 1
wall mounting bracket DB61-04402A 1
ASSY THERMISTOR-WATER TANK DB95-05023A 1
Ring band DB81-01572B 1
