Disassembly and Reassembly
Samsung Electronics 25
No Parts Procedure Remark
2 EXPANSION VESSEL 1) Remove the 2 screw from the front parts.
2) Separate the pipe connected expansion vessel
by 2 nut joints.
3 PUMP 1) Disconnect power and communication
connection.
2) Separate the pipe connected Pump by 2 nut
joints.
4 Flow sensor
1) Separate the pipe connected flow sensor
by 2 bracket holder.
To Next Page
