Disassembly and Reassembly
76 Samsung Electronics
No Parts Procedure Remark
1 CABI FRONT RH
You must turn off the power before
disassembling.
1) Unscrew and remove the three screws on the
CABI FRONT RH.
(Use '+' type screw driver)
2 CABI TOP 1) Unscrew and remove the nine screws
on each side of the CABI TOP.
(Use '+' type screw driver)
3 CABI INSTALL
FRONT
1) Unscrew and remove the screw
on the CABI INSTALL FRONT.
(Use '+' type screw driver)
■ AE080RXYD**
To Next Page
