Disassembly and Reassembly
82 Samsung Electronics
No Parts Procedure Remark
10 BRACKET MOTOR 1) Unscrew and remove the two screws
on the BRACKET MOTOR.
(Use ‘+’type screw driver)
11 HEATER 1) Unscrew and remove the three screws
on the BRACKET MOTOR.
(Use '+' type screw driver)
2) Disconnect the heater wire from
the ASSY CONTROL OUT.
To Next Page
