Disassembly and Reassembly
86 Samsung Electronics
No Parts Procedure Remark
15 ASSY PHE 1) Separate the pipe from the Entrance/Exit using
a welder.
2) As shown in the picture, unscrew and
remove the two screws from the BRACKET
PHE. (Use adjustable wrench)
16 ASSY COND OUT 1) Unscrew remove the two screws on each
side of the ASSY COND OUT.
(Use '+' type screw driver)
To Next Page
