Samsung Electronics 21
No Parts Procedure Remark
1 CABI FRONT RH
You must turn off the power before
disassembling.
1) Unscrew and remove the three screws on the
CABI FRONT RH.
(Use '+' type screw driver)
2 CABI TOP 1) Unscrew and remove the nine screws
on each side of the CABI TOP.
(Use '+' type screw driver)
3 CABI INSTALL
FRONT
1) Unscrew and remove the screw
on the CABI INSTALL FRONT.
(Use '+' type screw driver)
AEX100EDS/AEX125EDS/AEX140EDS/AEX160EDS
3-2 Outdoor Unit
To Next Page
