Samsung AM18A1(B1)E09 - Page 43

Samsung Electronics
6-6
6-3-2 PCB Box
Exploded Views and Parts List
1
2-4
2-6
2-2
2-1
2
3
2-5
2-3
No
1
2
2-1
2-2
2-3
2-4
2-5
2-6
3
CODE NO
DB61-10151A
DB93-10583A
DB93-00066A
DB93-00065A
DB09-10149A
DB32-10008D
DE26-20154A
2306-000294
3501-001058
DE32-10037A
DB93-10560B
DB93-10561B
Description
CASE-CONTROL
ASS'Y MAIN PCB
ASS'Y MAIN PCB
ASS'Y MAIN PCB
IC-MCU
THERMISTOR-ASS’Y
TRANS-POWER
C-FILM
POWER-RELAY
FUSE
ASS’Y PCB DISPLAY
ASS’Y PCB DISPLAY
Specification
ABS(94-5V)
-
-
-
MB89635R-466
103AT
AC230V DC17V 300mA
CFS 99N 450VAC 155K
DI1U DC12V
250V 3.15A
AI-GRILLE
BI-GRILLE
Q’TY
AM18A1(B1)E09 AM18A1(B1)B09 AM19A1(B1)E12 AM19A1(B1)E07
1
1
-
-
1
1
1
1
1
1
1
1
1
1
-
-
1
1
1
1
1
1
1
1
1
-
1
-
1
1
1
1
1
1
1
1
1
-
-
1
1
1
1
1
1
1
1
1
Remark
■
Parts List
