2. Product Specifications
2-1 Table
Model AM18A1(B1)E2 AM18A1(B1)B2 AM19A1(B1)E2
INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT
Item AM18A1(B1)E09 UM18A1(B1)E2 AM18A1(B1)B09 UM18A1(B1)B2 AM19A1(B1)E07 AM19A1(B1)E12 UM19A1(B1)E2
Type - Wall-Mounting Multi Split Wall-Mounting Multi Split
Cooling BTU/h 9,000 18,000(9,000x2) 9,000 18,000(9,000x2) 7,000 12,000 19,000 (7,000+12,000)
Dehumiditying I/h 1.6 - 1.6 - 1.2 1.9 -
Air volume Cooling m
3
/min 7.0 - 7.0 - 6.0 8.3 -
Noise Cooling dB 35 54 35 54 33 38 54
Power V-Hz 1-220-240V~, 50Hz 1-220V~, 60Hz 1-220V~, 50Hz
Power consumption Cooling W 870 1,740(870x2) 860x2 1,720(860x2) 720 1,230 1,820
Operating current Cooling A 3.7 7.4(3.7x2) 4.0 8.0(4.0x2) 3.1 5.3 8.0
Power factor Cooling % 97.9 97.7 96.0 96.0 94.0
Starting current A 30 30
Power cord(Option)
- HO7RNF 2.5 - H07RNF2.5 - - H07RNF2.5
HO5RNF (5G 1mm
2
) HO5RNF (5G 1mm
2
) H05RNF (5G 1mm
2
)
Fuse capacity A 3.15 - 3.15 - 3.15 3.15 3.15 / 5
Outer
W x H x D
mm 815x298x182 787x620x320 815x298x182 787x620x320 815x298x182 815x298x182 787x620x320
dimension
inch 32.08x11.73x7.17 30.98x24.41x12.6 32.08x11.73x7.17 30.98x24.41x12.6 32.08x11.73x7.17 32.08x11.73x7.17 30.98x24.41x12.6
Weight kg 9.6 53 9.6 53 9.6 9.6 53
Refrigerant pipe
Liquid
OD(mm)xL(m)
ø6.35 x 5 ø6.35 x 5 ø6.35x5 ø6.35x5 -
GAS
ø9.52x5 ø9.52 x 5 ø9.52x5 ø12.7x5 -
Drain hose ID(mm) x L(m) ø17 x 2,000 ø17x2,000
Type - Rotary - Rotary Rotary Rotary Rotary
Comp-
Model name - 44B092JW1E6 - 44B092IW1E5 44A070JW1E1 48A124JV1E5 44A070JW1E1 + 48A124JV1E5
Capacitor - 30µF x 420VAC - 20µF x 450VAC 25µF x 450VAC 30µF x 420VAC 20µF x 450VAC + 30µF x 420VAC
ressor
Motor
Tape(model) - - - - - - -
Rated output W - 675 - 675 675 1,210 -
Type Cross-fan Propeller Cross-fan Propeller Cross-fan Cross-fan Propeller
Blower
Motor
Type Resin Still Resin Still Resin Resin Still
Rated output W 35 35 35 35 35 35 35
Heat exchanger 2Row 12Step 2Row 24Step 2Row 12Step 2Row 24Step 2Row 12Step 2Row 12Step 2Row 24Step
Refrigerant control unit A,B-UNIT ; Capillary Tube A,B-UNIT ; Capillary Tube.
Freezer oil capacity cc - 280 - 280 280 360 -
Refrigerant to change (R-22) g - 800x2 - 790x2 700 850 700 + 850
Protection device - MRA12037-12007 - MRA12032-12008 MST24AMN-12008 MRA12030-12008 -
Standard Conditions ISO R5151 Standard ARI Standard ISO R5151 Standard
•The basic performance test is based on the piping of 5MT. (Be sure to check the installing conditions as extension of the piping
may lead to performance degradetion.)
