Samsung AM18A1(B1)E09 - Page 48

Samsung Electronics
8-3
• DB93-10560B
No
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Description
PCB-DISPLAY
LED - LAMP
LED - LAMP
LED - LAMP
LED - LAMP
MODULE REMOCON
C-CERAMIC
R-CARBON
CONNECTOR WAFER
C-CERAMIC
DIOD SWITCHING
C/W DIS & MODULE
CASE-CENTER PCB UP
CASE-CENTERPCB LOW
SEAL DISPLAY UPP
SEAL CASE DISPLAY
CODE-NO
DB41-10204B
0601-001333
0601-001059
0601-001060
0601-001196
DB32-50027A
2202-000780
2001-000515
2001-000283
0401-000005
DB39-20346A
DB61-10191A
DB63-10494A
DB72-10233A
DB72-10220F
Specification
FR-1 T1.6 W20 L170
LTL-30EHJ(ORG/GRN)
SY5511(YEL)
SM5511(GRN)
SO5511(ORG)
PNA4612MOOXD
CA 0A 50V 104Z
RD 1/8TP 221-J
YWL A200-09P
CA 0A 50V 102Z
1N4148
UL1007 AWG#26/9
PC, BLUE
ABS, BLK
FOAM-PE, BLK
30FOAM-PE
Q’TY
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
■
PART LIST
8-2 ASS’Y DISPLAY & Module PCB
8-2-1 AM18A1E09/AM18A1B09/AM19A1E12/AM19A1E07
