PBA connection diagram
f ADN160BDE✴✴
V1
V2
L
N
Power cable (1 Phase AC
220~240 V)
Wired remote
controller
Outdoor unit
(Communication cable)
f AM✴✴✴FNBD✴✴
V1
V2
L
N
Power cable (1 Phase AC
220~240 V)
Wired remote
controller
Outdoor unit
(Communication cable)
