Samsung AM320FNBDEH/EU - Hydro Unit

7
ENGLISH
Hydro unit
<When installing one product on top of the other one>
(Unit: mm)
100
400
600
100100
100
200
626 626
Service space
H beam
Hydro unit HT
600 mm
600 mm
300 mm
400 mm
100 mm
t If the Hydro unit / Hydro unit HT is needed to installed closed to the walls unavoidably, prevent the vibration
generated from the product to the walls with cushioning materials etc.
CAUTION
