Wiring diagram for connecting 2 wired remote controllers
f ADN✴✴✴BDE✴✴
V1
V2
L
N
Wired remote controller (slave)
Wired remote controller (master)
f AM✴✴✴FNBD✴✴ / AM✴✴✴FNBD✴✴
V1
V2
L
N
Wired remote controller (slave)
Wired remote controller (master)
